Welding Cable Red Black 2 AWG GAUGE COPPER WIRE BATTERY CAR SOLAR LEADS

Product Name:

Welding Cable Red Black 2 AWG GAUGE COPPER WIRE BATTERY CAR SOLAR LEADS

Number :

Product Description:

Welding Cable Red Black 2 AWG GAUGE COPPER WIRE BATTERY CAR SOLAR LEADS

Standard
The welding cable can be produced according to the standard 245 IEC 81, ICEA S-75-381

Specific Property for application
(1).The cable can be used in the connectors of electric weld and pliers of the electrical welding whose toward earth
voltage ofthe low voltage is not more than AC 200 V and the pulsant DC peak value is 400V.
(2).The long-time permissible working temperature of cable is not more than 65.

Name and IEC Standard
(1)Rubber Sheathed Welding Cable 245 IEC 81
(2)Rubber Sheathed Welding Cable 245 IEC 82, which is made of chloroperene or the composite stretchy materials.

Constructions
Conductor Materials:Copper, Tinned Copper or CCA
Jacket:Rubber or PVC

Technical Data of DC Battery Cables
Cable Type	BVR
Popular Size	10mm,16mm,25mm,35mm,50mm
Gauge	8AWG, 6AWG, 4AWG, 2AWG, 1AWG
Conductor	99.7% Stranded Bare Copper
Insulation Material	PVC
Standard	GB/T 19666-2005, JB/T8734.2-2006
Rated Voltage	450V/750V
Diameter of Lug’s Aperture	M6,M8,M10
Temperature	70℃
Color	Black,Red
Length	20/30/40/50/60/80/100 cm and customized
Lug installation method	Crimping
Application	Used for connection of car battery, battery, inverter, etc.

AWG Size	Conductor Stranding	Nominal thickness sheath (in)	Overall Diameter (in)	Approx LBS/MFT
6	259/0.30mm	0.065	0.305	113
4	385/0.30mm	0.06	0.34	147
2	651/0.30mm	0.07	0.42	265
1	779/0.30mm	0.084	0.498	330
1/0	1026/0.30mm	0.085	0.525	405
2/0	1254/0.30mm	0.084	0.57	485
3/0	1615/0.30mm	0.093	0.635	620
4/0	2052/0.30mm	0.083	0.695	790
250	2451/0.30mm	0.148	0.875	1110
350	3432/0.30mm	0.137	0.96	1310
500	5054/0.30mm	0.16	1.2	1960
