Welding Cable Red Black 4 AWG GAUGE COPPER WIRE BATTERY CAR SOLAR LEADS
 |
Product Name:
Welding Cable Red Black 4 AWG GAUGE COPPER WIRE BATTERY CAR SOLAR LEADS
Number :
 |
Product Description:
Welding Cable Red Black 4 AWG GAUGE COPPER WIRE BATTERY CAR SOLAR LEADS
Application
battery cable is often used in main power applications in small cars, RV trailers, golf carts, and small marine crafts.
Also great for smaller solar cable applications.
Be aware that the total length of both the positive and negative cables have to be considered
Construction
conductor: 99.9% pure copper strands wire
insulation: PVC
The average outside diameter of the cable is approximately 0.330 inches.
Rated for low voltage and battery use up to 60 volts DC and 25 Volts AC.
The internal copper stranded core is highly conductive maximizing current flow while still being highly flexible.
| Technical Data of DC Battery Cables | |
| Cable Type | BVR |
| Popular Size | 10mm,16mm,25mm,35mm,50mm |
| Gauge | 8AWG, 6AWG, 4AWG, 2AWG, 1AWG |
| Conductor | 99.7% Stranded Bare Copper |
| Insulation Material | PVC |
| Standard | GB/T 19666-2005, JB/T8734.2-2006 |
| Rated Voltage | 450V/750V |
| Diameter of Lug’s Aperture | M6,M8,M10 |
| Temperature | 70℃ |
| Color | Black,Red |
| Length | 20/30/40/50/60/80/100 cm and customized |
| Lug installation method | Crimping |
| Application | Used for connection of car battery, battery, inverter, etc. |
| Conductor Section area (AWG) |
Core No. /Dia. (No./mm) |
Nominal thickness sheath (mm) |
Overall Diameter (mm) |
Max. d.c. resistance at 20°c (Ω/km) |
Approx. Weight (kg/km) |
||
| Min. | Max. | YH | YHF | ||||
| 8 | 322/0.20 | 1.8 | 7.5 | 9.7 | 1.91 | 146 | 153.51 |
| 6 | 513/0.20 | 2 | 9.2 | 11.5 | 1.16 | 218.9 | 230.44 |
| 4 | 798/0.20 | 2 | 10.5 | 13 | 0.758 | 316.6 | 331.15 |
| 2 | 1121/0.20 | 2 | 11.5 | 14.5 | 0.536 | 426 | 439.87 |
| 1/0 | 1596/0.20 | 2.2 | 13.5 | 17 | 0.379 | 592.47 | 610.55 |
| 2/0 | 2214/0.20 | 2.4 | 15 | 19.5 | 0.268 | 790 | 817.52 |
| 3/0 | 2997/0.20 | 2.6 | 17 | 22 | 0.198 | 1066.17 | 1102.97 |
