Product Name:
Flexible Home Appliances Used Silicone Rubber Cable
Number :
 |
Nominal Voltage: 300V
Temperature Range: -60 ° C ~+150° C
Testing Voltage: 2000V
Conductor: Bare Copper or Tinned Copper
Insulator: Silicone Rubber
Colours: White-Blue-Red-Black-Brown-Yellow-Green-Transparent-Yellow/Green
Characteristic:
it has excellent high temperature &low temperature resistance, excellent electrical insulation properties, excellent chemical stability, high voltage resistance,
ageing resistance, long service life.And soft, easy to install.
Application:
Widely used in lighting, household appliances, electric appliances, instrument, electrical and electronic wiring, lamps and lanterns, burner and high temperature
environment.
Flexible Home Appliances Used Silicone Rubber Cable
|
Silicone Rubber Insulated Wire |
|||||
|
AWG |
Conductor No./Dia |
Overall Diameter (mm) |
Insulation Thickness (mm) |
Overall Diameter (mm) |
Packing Length(metre) |
|
30 |
7/0.103 |
0.31 |
0.76 |
1.83 |
610 |
|
28 |
7/0.127 |
0.38 |
0.76 |
1.9 |
610 |
|
26 |
7/0.160 |
0.49 |
0.76 |
2.01 |
305 |
|
24 |
7/0.203 |
0.61 |
0.76 |
2.13 |
305 |
|
22 |
7/0.254 |
0.76 |
0.76 |
2.28 |
305 |
|
20 |
7/0.310 |
0.94 |
0.76 |
2.47 |
305 |
|
18 |
7/0.39 |
1.17 |
0.76 |
2.71 |
305 |
|
16 |
7/0.5 |
1.5 |
0.76 |
3.02 |
305 |
